Part No.:YH110000-00
Design Temperature: 110℃
Weight:0.92kg
The Fusible Link is designed to break at at 110+5℃ (212F)，This part is easy to install on tanks and fits on various tank types and foot valves.
Associated Parts
| Part No. | Description |
| JS468001-15 | Foot valve Operating Lever |
| SNRA1101 | St. St. Wire 2.5mm 7×7 Length:6.5m |
| SNRA1102 | Wire Clip |
| SNRA1103 | Remote Control Spring |
Part Drawing
Set up instructions :
Fix the device on the tank frame with M8 screws or by welding
Connect the link and remote control wire by chain
Make sure the foot valve is in open position.
| Item | Part No. | Description | Material |
| 1 | YH110000-01 | Holder | 304 |
| 2 | YH110000-02 | Spring | 302 |
| 3 | YH110000-03 | Arm | CF8 |
| 4 | YH110000-04 | Fusible Part | H62 |
| 5 | YH110000-05 | Link | CF8 |
